Awaiting product image

DIN Type

In Stock
Enquire Now
1-4 DAYS DELIVERY
100% ORIGINAL AND QUALITY
3 MONTHS GUARANTEE

Description

DIN TYPE
SPECIFICATION
Group Number
Type
Voltage (V)
C20 (Ah)
RC (min)
CCA 0F (-18C)A
 Maximum Overall Dimension (mm)
Cell Layout
Terminal
Hold Down
Handles
L W H TH
B20
 53520 12 36 54 335 195 126 201 222 0 3 B0 B0
53521 12 36 54 335 195 126 201 222 0 1 B0 B0
53522 12 36 54 335 195 126 201 222 1 3 B0 B0
53534 12 36 54 335 195 126 201 222 1 1 B0 B0
LB1
 53628 12 36 54 330 206 174 173 173 1 1 B13 B13
53654 12 36 54 330 206 174 173 173 0 1 B13 B13
54316 12 44 68 410 206 174 173 173 0 1 B13 B13
54465 12 44 68 410 206 174 173 173 0 1 B13 B13
54466 12 44 68 410 206 174 173 173 1 1 B13 B13
L1
 54459 12 44 68 410 207 174 190 190 0 1 B13 B13
54464 12 44 68 410 207 174 190 190 1 1 B13 B13
D23
 56068 12 60 98 520 231.5 172 202 223 0 1 B0 B0
56069 12 60 98 520 231.5 172 202 223 1 1 B0 B0
B24
 54523 12 45 70 410 236 128 200 222 0 1 B0 B0
54524 12 45 70 410 236 128 200 222 1 1 B0 B0
54551 12 45 70 350 236 128 200 222 1 3 B0 B0
54584 12 45 70 350 236 128 200 222 0 3 B0 B0
LB2
 54519 12 45 70 430 242+0-2 175+0-2 175+0-4 175+0-4 0 1 B13 B13
55046 12 50 79 470 242+0-2 175+0-2 175+0-4 175+0-4 0 1 B13 B13
55218 12 55 88 520 242+0-2 175+0-2 175+0-4 175+0-4 0 1 B13 B13
L2
 55530/55559/55573 12 55 88 500 242+0-2 175+0-2 190+0-3 190+0-3 0 1 B13 B13
55565 12 55 88 500 242+0-2 175+0-2 190+0-3 190+0-3 1 1 B13 B13
56219 12 60 98 550 242+0-2 175+0-2 190+0-3 190+0-3 0 1 B13 B13
56221 12 60 98 550 242+0-2 175+0-2 190+0-3 190+0-3 1 1 B13 B13
LB3
 55415 12 54 87 460 276 174 174 174 0 1 B13 B13
56420 12 65 108 570 276 174 174 174 0 1 B13 B13
57113 12 68 114 600 276 174 174 174 0 1 B13 B13
L3
 56618 12 66 110 560 278+0-2 175+0-2 190+0-3 190+0-3 0 1 B13 B13
57219 12 72 122 620 278+0-2 175+0-2 190+0-3 190+0-3 1 1 B13 B13
57220 12 72 122 620 278+0-2 175+0-2 190+0-3 190+0-3 0 1 B13 B13
57412 12 75 128 640 278+0-2 175+0-2 190+0-3 190+0-3 0 1 B13 B13
57545 12 75 128 640 278+0-2 175+0-2 190+0-3 190+0-3 0 1 B13 B13
27R 58513 12 83 144 660 303 170 201 222 0 1 B1 B1
27 58514 12 83 144 660 303 170 201 222 1 1 B1 B1
L4 58211 12 78 135 650 314 174 174 174 0 1 B13 B13
LB4 58043 12 80 138 650 314 174 190 190 0 1 B13 B13
LB5
 58515 12 85 148 670 351 174 173 173 173 1 B13 TS6
58815 12 88 154 710 351 174 173 173 173 1 B13 TS6
L5
 58821 12 88 154 690 351 174 188 188 188 1 B13 TS6
58827 12 88 154 690 351 174 188 188 188 1 B13 TS6
59218 12 88 154 690 351 174 188 188 188 1 B13 TS6
59040 12 95 169 730 351 174 188 188 188 1 B13 TS6
59524 12 95 169 730 351 174 188 188 188 1 B13 TS6
60038 12 98 175 770 351 174 188 188 188 1 B13 TS6
E41
 60026 12 100 179 750 408±3 170 209 233 233 1 B0 TS8
60525 12 105 190 780 408±3 170 209 233 233 1 B0 TS8
